A high performance server with two pre-installed e:cue software applications designed to control small to medium projects.
Overview Technical Specifications Downloads Solutions Overview
- Equipped with e:cue’s SYMPHOLIGHT and e:cue’s Lighting Application Suite
- Fanless operation, no moving or rotating parts due to an SSD-drive
- High quality components for reliable uninterrupted operation, certified for industrial use
- Supports a variety of Ethernet-based protocols
- Easily mountable onto DIN rail (not included) or onto walls
- Supports headless operation (no keyboard and monitor needed)
- e:cue quality: tested, approved and optimized for SYMPHOLIGHT
- SYMPHOLIGHT and LAS licenses included
- Power supply included
- Windows 10 LTSC, 10 years security updates
- 5 years support
- 5 years warranty
Designed to control small to medium projects, the Lighting Control Engine 3 mx (LCE3MX) is a high performance server with two e:cue software applications installed. As a central control unit, this versatile lighting control server orchestrates all devices and fixtures within a project. With the ability to output e:net and the capability to integrate various external engines, triggers, and other desired devices and content, the LCE3MX is an ultimate solution for demanding projects: from automation to DALI projects up to medium architectural illumination. The LCE3MX can be mounted on DIN rails with the optional DIN rail adapter brackets, on walls, and in 19 inch racks mounted on a rack drawer.
IC: AS086160055
Certifications & Approbations
Can’t find what you are looking for?
Do you need a custom product?
Looking for fixture options?
Technical Specifications
Dimensions (W x H x D) | 174 x 148 x 57 mm / 6.85 x 5.83 x 2.24 in (incl. mounting brackets) |
Weight | 1.35 kg / 2.98 lb (incl. mounting brackets) |
Power Supply | External 12 V DC, 5 A |
Power Consumption | 60 W |
Operating Temperature | -10 … 60 °C / 14 … 140 °F |
Storage Temperature | -20 … 70 °C / -4 … 158 °F |
Relative Humidity | 5 … 95% RH, non-condensing |
Housing | Metal |
Mounting | Wall mounting |
Battery | Yes (1) |
Certification | CE, UKCA |
Operating System | Microsoft® Windows 10™ |
LAN Chipset | 2 x Gigabit Ethernet, Wake on LAN function |
System Connection Ports |
2 x e:net (RJ45 Ethernet for GbE) |
Data Storage | 128 GByte SSD SATA HDD 1 x SATA DOM |
User Interfaces |
AC loss switch |
